| SNOW SCIENCE | hub rotating assembly to a compressor impeller in a separate cavity.
This compressor wheel draws fresh air from the atmosphere and accelerates it outward. As air leaves the impeller, it slows inside the compressor housing, converting velocity into pressure before entering the intake tract. Both the compressor and turbine housings have an area-to-radius( A / R) ratio that plays a major role in spool characteristics, airflow capacity, and overall turbo behavior. Together with wheel sizing, these dimensions form the compressor map engineers use when designing a turbocharged engine.
Aspect ratios can be altered within a Variable Geometry Turbocharger( VGT). It serves to reduce lag at low engine rpm or low exhaust flow. At low engine speeds, the vanes close to accelerate exhaust flow through the turbine, increasing turbine speed and reducing lag. As engine speed and exhaust flow increase, the vanes progressively open to prevent excessive turbine speed and reduce exhaust restriction.
The air entering the engine on many turbocharged engines comes solely from the compressor. This means that any oxygen desired by the engine must pass through the turbocharger regardless of the load placed on the mill. Oftentimes this can lead to a lag where the engine doesn’ t perk to life immediately, which is a hindrance for quick, rapid throttle movements where response is critical. To combat this effect, short intake tracts with minimal distance between the turbocharger and throttle blades serve to improve feel. Other nifty features, such as bypass valves, allow naturally aspirated air to reach the engine while the turbo is still building boost. Once boost pressure exceeds atmospheric pressure, the bypass closes and all intake air flows through the compressor.
With thermodynamics at work on the system, the compressed air entering the engine will increase in temperature. Since warm air is less dense than cool air, a component often seen between the turbocharger and the throttle blades is an intercooler to reduce this temperature. Cooling the compressed air increases density, improves volumetric efficiency, and reduces the likelihood of detonation.
Consuming more air per stroke of the piston also means more fuel is needed to maintain the proper air-fuel ratio. The ECU must increase its pulse width per injection cycle to accommodate this. Not only will the fuel be increased back to naturally aspirated burn conditions, but it will also be slightly richer to keep the components cooler.
If an engine ran at 13.2:1 compression at wide-open throttle, the same engine equipped with a turbocharger may run 11.7:1 in the same conditions. As extra cylinder pressure is present in the boosted case, this extra unburnt fuel serves to keep metallic surfaces cooled, prolonging the life of critical components.
Polaris and Ski-Doo both use turbocharged twin-cylinder 2-strokes, but they do not achieve that goal using identical methods. Let’ s take a look at how each system works and the major components involved on each sled.
POLARIS: PATRIOT BOOST
Polaris builds its factory turbo system around the 840cc Patriot engine and force feeds it with a turbocharger. Polaris centers its Patriot Boost system
around a compact, vertically mounted turbocharger with a reverse-rotating turbine, a layout chosen to shorten airflow paths and improve response. The reverse-rotation design allows the compressor outlet and exhaust flow to align with the sled’ s compact vertical packaging, minimizing runner length to improve throttle response and reduce perceived lag. The scalloped turbine wheel reduces rotating mass and improves energy capture, aiding quicker spool-up and responsiveness.
This system is electronically controlled through its SmartBoost strategy, with boost and engine operation managed by the ECU. A reed valve in the boost box allows air to enter the engine while the turbo is still building pressure, which improves low-rpm response and reduces the lag riders often associate with turbocharged engines. A dedicated oil supply arrangement provides lubrication for the turbo.
Overall, the Polaris system is designed to create boost quickly, manage it automatically, and package the turbo hardware without dramatically changing the sled’ s mountain-focused handling.
