Turf Tank Two line marking robot
The updated Turf Tank Two line marking robot has been meticulously crafted , utilizing robust research and development , constructive feedback from users and a focus on elevating the user experience to new heights The Turf Tank Two incorporates dual motor drives for enhanced momentum and optimized wheels for superior traction , resulting in marking times that raise the bar in the industry , including football in 3 hours and 29 minutes and an 11v11 soccer pitch in less than 24 minutes . The Turf Tank Two boasts more than 120 layouts and more than 10,000 combinations , based on individual dimensions and needs .
The sprayer module has been significantly upgraded to make fine-tuning as straightforward as a twist of a knob . It adjusts disc height and width , and includes a disc ruler for improved oversight . Precise tolerances deliver sharp , crisp lines between 5 and 15cm . The rack-and-pinion system allows for easy adjustment from minimum to maximum in one smooth motion . The height of the sprayer discs can be easily adjusted in 5mm increments .
Maintenance has also been simplified , with the module now designed as a separate component . Just by loosening two screws , users can easily access specific parts ; and a one-hand solenoid removal feature allows for quicker working when the robot has finished painting .
A new front panel offers convenient pause / resume options with LED indicators that display the robot ’ s status along with a start / stop sprayer button . An LED indicator on the battery ensures a swift status check — even when the battery is not plugged in . To make for even smarter operating , batteries can now be replaced without the need to power down the robot .
A newly designed compartment increases both efficiency and the ease with which paint is inserted . Bypassing the need for heavy lifting , the tilted pump cover permits up to 20 liters of paint to be easily slid into the robot and ensures that the suction rod can extract and use all the paint . Battery access has been
simplified , requiring a single movement to lock it in place . Additionally , handles on the front and back make loading and unloading from vehicles easier .
In the palm of your hand is where the user experience is propelled to new heights . Users can now batch edit fields , place layouts inside layouts ( e . g ., an 11v11 soccer pitch with two 8v8 fields inside ), as well as design custom routes and measure directly on the map .
All of these functions are performed within the comprehensive visual layout editor that lets users change or remove any line of a field . Any line can be made dashed , new lines can be added to existing layouts and new layouts can be converted into templates for future use . All templates within the app can be swiftly moved and precisely placed using the drag-and-drop features .
Brand new in-app guides help users navigate through most features , and a newly integrated wizard provides a walkthrough for the cleaning and priming process of the paint system .
To make sure that lines are staying straight , a new augmented reality calibration routine guides users to correct any discrepancies by simply using the tablet ’ s built-in camera to take a picture of the painted lines .
These features are also available in Offline Mode , ensuring full functionality of the Turf Tank Two even when an internet connection is not available .
Turf Tank Customer Service can now help customers through remote access , which allows them to assist in setting up pitches , diagnose problems and provide support instantly wherever the user is .
Trilo T1 vacuum
The Trilo T1 vacuum , available from STEC , is a debris loader designed to transform your utility cart into a vacuum sweeper . Simply place the skid-mounted T1 into the bed of the utility cart and it is ready for use . Remove the T1 when done and your cart is reverted back to its normal functions . The compact size and design allow the unit to reach places most sweepers and vacuums can ’ t , such as fence lines or along buildings .
